TV Connection(Using component Video In jack (Pr Pb Y)


  1. Use the component video cables (red/blue/ green) to connect the system’s Pr Pb Y jacks to the corresponding Component video input jacks (or labeled as Pr/Cr Pb/Cb Y or YUV) on the TV set.
  2. To listen to TV channels through this system, use the audio cables (white/red) to connect AUX IN jacks to the corresponding AUDIO OUT jacks on the TV set.
  3. If you are using a Progressive Scan TV set (TV with Progressive Scan or ProScan capability), activate the PROGRESSIVE SCAN function through SYSTEM MENU.

TV Connection using component Video in jack(Pr Pb Y)(Example Only)
