Turn off the DVD player before doing the connection

AV OUT Connection ( How to use AV IN )

1. On the DVD player panel, press AV IN/OUT to select A/V OUT.
2. Connect Mini plug to the AV OUT jack of the player.
3. Connect Red plug to the AUDIO IN R jack and White plug to AUDIO IN L jack of the additional equipment(such as TV).

AV OUT Connection(Example Only)


AV IN Connection ( How to use AV OUT )

1. On the DVD player panel, press AV IN/OUT to select A/V IN .
2. Connect Mini plug to the AV IN jack of the player.
3. Connect Red plug to the AUDIO IN R jack and White plug to AUDIO IN L jack of the additional equipment(such as TV).

AV IN Connection(Example Only)
